FORTUNER SPECS SHEET
VEHICLE |
FORTUNER (4X4 Hi) | FORTUNER (4X2 Hi) | |
| MODEL CODE | GUN156R-SPTMHP | TGN166R-SPTSKP | |
| DIMENSIONS | |||
| Exterior | L x W x H (mm) | 4795 x 1855 x 1835 | 4795 x 1855 x 1835 |
| Wheelbase | (mm) | 2750 | 2750 |
| Tread | Front (mm) / Rear (mm) | 1540 / 1555 | 1540 / 1555 |
| Overhang | Front (mm) / Rear (mm) | 990 / 1060 | 990 / 1060 |
| Min. Running Ground Clearance | (mm) | 279 | 279 |
| Min. Turning Radius | Body (m) | 6.2 | 6.2 |
| Interior | L x W x H (mm) | 2478 x 1478 x 1105 | 2478 x 1478 x 1105 |
| Seating Capacity (persons) | 7 | 7 | |
| Gross Vehicle Weight | Total (kg) | 2735 | 2500 |
| Curb Weight | Min. Options (kg) | 2095 | 1835 |
| Fuel Tank Capacity | Total (L) | 80 | 80 |
| ENGINE SPECIFICATION | |||
| Engine Code | 1GD - FTV (Hi)(New) | 2TR - FE | |
| Intercooler(New) | O | X | |
| Displacement (cm3) | 2755 | 2694 | |
| No. of Cyls. & Arrangement | 4 cylinders, IN LINE | 4 cylinders, IN LINE | |
| Fuel System | COMMON - RAIL - DIESEL(New) | SEQUENTIAL MULTIPORT FUEL INJECTION - PETROL | |
| Max. Output (kW @ rpm) | 130 @ 3400 | 122@5200 | |
| Max. Torque (N·m @ rpm) | 450 @ 1600 - 2400 | 245 @ 4000 | |
| PERFORMANCE | |||
| Transmission | Code | AC60F | AC60E |
| Type | 6-Speed Sequential with Paddle Shifters | 6-Speed Sequential with Paddle Shifters | |
| Transfer | System | Part-Time H2 , H4 , L4 | X |
| Type | Switch Type | ||
| Rear Differential Lock | Yes, Automatic Disconnect Differential | X | |
| Brake Type | Front + Rear | Ventilated Disc Brake | Ventilated Disc Brake |
No Broucher Found.
Fortuner-G Petrol 4x2 AT LOW 2.7L 9,499,000/=
Transportation 42,500 /=
W.H.T For Filler 200,000 /=
W.H.T For Non Filler 400,000 /=
Fortuner-V Petrol 4x4 AT Hi 2.7L 10,949,000/=
Transportation 42,500 /=
W.H.T For Filler 200,000 /=
W.H.T For Non Filler 400,000 /=
Fortuner Sigma Diesel 4x4 AT 11,489,000/=
Transportation 42,500/=
W.H.T For Filler 200,000/=
W.H.T For Non Filler 400,000 /=
Fortuner Legender Diesel 4x4 AT 12,099,000/=
Transportation 42,500/=
W.H.T For Filler 200,000/=
W.H.T For Non Filler 400,000 /=
*Vehicle with delivery time above 30 Days can be book on Partial payment of Rs. 3,000,000/- (Terms & Conditions Apply)
